Quadruped Robot Dog with Artificial Intelligence – Specifications:
- Standing dimensions: 645 mm (L) x 280 mm (W) x 400 mm (H)
- Folded dimensions: 540 mm (L) x 290 mm (W) x 130 mm (H)
- Weight: 12 kg (with battery)
- Load Capacity: 5 kg (EDU version), 3 kg (other versions)
- Maximum Speed: 3.7 m/s (Air version: 2.5 m/s)
- Operating Time: 1-2 hours
- Maximum Climb Angle: 35°
- Degrees of Freedom (DOF): 12 (3 per leg)
- Power Outputs: 5V, 12V, 24V
- External Interfaces: HDMI x3, Gigabit Ethernet port x1, USB x3, Integration Interface x1
- Control Modes: Remote, slide-follow, autonomous
- Processor: 16-core CPU + GPU (384 cores, 1.5 TFLOPS)
- Sensors: 5 sets of fisheye binocular depth sensors, Ultrasonic sensors, Foot force sensors (EDU version), High-precision laser radar (2D and 3D lidar), Inertial Measurement Unit (IMU)
- Battery Life: 4 hours
- Communication: WiFi, 4G/5G, Bluetooth
- Software: Real-time operating systems (Ubuntu, Ubuntu-ROS)
- Programming Languages: C++, Python, Graphical programming
