| Specification | US-GS880BH | US-GS191BH-YHX | US-GS240BH-YHX | |
| LCD Panel | Screen Size (Diag.) | 8.8″ | 19.1″” | 24″ |
| Resolution | 1920X480@60Hz | 1920×360 | 1920×360@60Hz | |
| Display Colors | 16.7M (8bit) | 16.7M (8bit) | 16.7M (8bit) | |
| Aspect Ratio | 16:03 | 16:03 | 16:03 | |
| Brightness (w/o TP) | 350cd/m2 | 350cd/m2 | 300cd/m2 | |
| Contrast Ratio | 3000:1 | 1400:1 | 1000:1 | |
| Viewing Angle(H/V) | 178°/178° | 178°/178° | 178°/178° | |
| Response Time(G to G) | 6ms | 6ms | 6ms | |
| Display area | 218.88 (H) x 54.72 (V) | 476.64 (H) x 89.37 (V) | 531.36 (H) x 289.89 (V) | |
| Unit outline dimensions | 239(H) x 67(V) x 21 (B) | 491.5(H) x 109.4(V) x 8.4 (B) | 625(H) x 149(V) x 40 (B) | |
| light Unit | LED | LED | LED | |
| Backlight Life | 30,000 Hours | 30,000 Hours | 30,000 Hours | |
| Specification | Mainboard spec max | / | / | / |
| Single power spec max | 120mm(H) x 70mm(V) | / | / | |
| Power plate spec max | / | / | / | |
| interface | Boat Type Switch | x1 | X1 | X1 |
| Eight words tail power plug | X1 | X1 | X1 | |
| Remote Control Plate | / | X1 | X1 | |
| Sound | Built-in Speakers | 8Ω5W | 8Ω5W | 8Ω5W |
| Network interface | Wifi | yes | yes | yes |
| 3G/4G | optional | optional | optional | |
| Power | Input Power | DC 12V / 220V | DC 12V / 220V | DC 12V / 220V |
| Power Consumption (Typical) | 20w | 38w | 38w | |
| Power Consumption (Standby) | 1W | 1w | 1w | |
| Packaging spec | Packing size | 244mm(H)×72mm(V)×26mm(W) | 620mm(H)×80mm(V)×26mm(W) | 620mm(H)×80mm(V)×26mm(W) |
| Net weight | 3KG | 3.8KG | 3KG | |
| Gross weight | 4KG | 4.6KG | 5KG | |
| Fixed mode | Wall Mounting Bracket | 500mm(H)×100mm(V) | 120mm(H)×35.4mm(V) | 120mm(H)×35.4mm(V) |
| Environmental Conditions | Operating Temp. | 0℃~50℃ | 0℃~50℃ | 0℃~50℃ |
| Operating Humid. | 0%~90% | 0%~90% | 0%~90%
|
| Specification | US-GS280BH-YHX | US-GS355 | US-GS439 | US-GS495 | |
| LCD Panel | Screen Size (Diag.) | 28” | 35.5” | 43.9” | 49.5” |
| Resolution | 1920×360 | 1920×360 | 1920×540 | 1920×540 | |
| Display Colors | 16.7M (8bit) | 1.07B | 1.07B | 1.07B | |
| Aspect Ratio | 16:3 | 16:3 | 16:4.5（32:9） | 16:4.5（32:9） | |
| Brightness (w/o TP) | 350cd/m2 | 350cd/m2 | 350cd/m2 | 350cd/m2 | |
| Contrast Ratio | 1400:1 | 4000:1 | 5000:1 | 5000:1 | |
| Viewing Angle(H/V) | 178°/178° | 178°/178° | 178°/178° | 178°/178° | |
| Response Time(G to G) | 6ms | 8ms | 6.5ms | 6ms | |
| Display area | 698.4mm(H)×130.9mm(V) | 885.6mm(H)×166mm(V) | 1073.8mm(H)×302mm(V) | 1209.6mm(H)×340.3mm(V) | |
| Unit outline dimensions | 729.2mm(H)×161.6mm(V)×55mm(W) | 916.6mm(H)×197.2mm(V)×55mm(W) | 1103.8mm(H)×332.8mm(V)×55mm(W) | 1239.6mm(H)×370.8mm(V)×55mm(W) | |
| light Unit | LED | LED | LED | LED | |
| Backlight Life | 30,000 Hours | 30,000 Hours | 30,000 Hours | 30,000 Hours | |
| Specification | Mainboard spec max | ||||
| Single power spec max | 120mm(H)×70mm(V) | 120mm(H)×70mm(V) | 180mm(H)×85mm(V) | 180mm(H)×85mm(V) | |
| Power plate spec max | / | / | 187mm(H)×120mm(V) | 187mm(H)×120mm(V) | |
| interface | Boat Type Switch | X1 | X1 | X1 | X1 |
| Eight words tail power plug | X1 | X1 | X1 | X1 | |
| Remote Control Plate | X1 | X1 | X1 | X1 | |
| Sound | Built-in Speakers | 8Ω5W | 8Ω5W | 8Ω5W | 8Ω5W |
| Network interface | Wifi | yes | yes | yes | yes |
| 3G/4G | optional | optional | optional | optional | |
| Power | Input Power | DC 12V / 220V | DC 12V / 220V | DC 12V / 220V | DC 12V / 220V |
| Power Consumption (Typical) | 40w | 45w | 60w | 65w | |
| Power Consumption (Standby) | 1W | 1W | 2W | 2W | |
| Packaging spec | Packing size | 820mm(H)×250mm(V)×95mm(W) | 1005mm(H)×275mm(V)×95mm(W) | 1195mm(H)×420mm(V)×95mm(W) | 1330mm(H)×460mm(V)×95mm(W) |
| Net weight | 4.5KG | 6.5KG | 10KG | 12.5KG | |
| Gross weight | 5.6KG | 7.5KG | 12.5KG | 15KG | |
| Fixed mode | Wall Mounting Bracket | 500mm(H)×80mm(V) | 500mm(H)×100mm(V) | 500mm(H)×200/100mm(V) | 500mm(H)×200/100mm(V) |
| Environmental Conditions | Operating Temp. | 0℃~50℃ | 0℃~50℃ | 0℃~50℃ | 0℃~50℃ |
| Operating Humid. | 0%~90% | 0%~90% | 0%~90% | 0%~90% |
