HUAWEI Three phase solar inverter SUN2000-8KTL-M1
Smart PV string inverter:
- High efficiency inverter topology, Max. Efficiency 98.6%
- Can be combined with Huawei Smart PV Optimizer SUN2000-450W-P, enables more modules on rooftop
- Up to 30% higher yields contributed by optimizing each panel performance
- Hybrid inverter with battery input
- Integrated battery interface for future quick battery connection without extra device or retrofit cost
- Ripple control receiver interface
- AI-based arc detection AFCI
- Communication:
– Smart dongle-WLAN-FE (integrated)
– Smart dongle-4G (optional)
Features:
- Recommended max. PV input power: 12000 Wp
- Max. input voltage: 1100 V
- Number of MPP trackers / Input number per MPP tracker: 2 / 1
- Battery Input operating voltage range: 600 V – 980 V
- Battery Input Max. operating current: 16 A
- Rated output power: 8 kW
- Rated output voltage: 220 Vac / 380 Vac, 230 Vac / 400 Vac, 3W / N+PE
- Max. output current: 13,5 A
- DC and AC surge protection: Surge arresters SPD2
- Degree of protection: IP65
- Weight (incl. mounting bracket): 17 kg
- Dimension (incl. mounting bracket): 525 x 470 x 146,5 mm
