Specifications:
|
Flexible Modules
|
P1.25
|
P1.579
|
P1.667
|
P1.875
|
P4
|
|
LED SMD Mode
|
SMD1010
|
SMD1010/SMD1212
|
SMD1212/1515
|
SND1515
|
|
|
Pixel Pitch
|
P1.25mm
|
P1.579mm
|
P1.667mm
|
P1.875mm
|
2.5mm
|
|
Pixel Density (dots/㎡)
|
640000
|
401111
|
360000
|
284444
|
160000
|
|
Module Resolution
|
176X99dots
|
204X114dots
|
192X108dots
|
144X81dots
|
128X72dots
|
|
Scan Mode
|
1/48
|
1/38
|
1/36
|
1/32
|
1/15
|
|
Module Size（mm）
|
240x120x8.6mm
|
||||
|
Refresh Rate（Hz）
|
3840
|
≥2880
|
≥1920
|
||
|
Repetiotion Frequency（Hz）
|
50&60
|
||||
|
Module Bottom Shell Material
|
Silicone Soft Bottom Case
|
||||
|
Module Weight（kg/pcs）
|
0.215
|
0.203
|
0.195
|
0.216
|
0.170
|
|
Cabinet Size
|
Customized
|
||||
|
Cabinet Material
|
Sheet metal sandblasted iron cabinet
|
||||
|
Cabinet Flatness（mm）
|
≤ 0.2
|
≤ 0.3
|
|||
|
Protection Grade
|
IP45
|
||||
|
Installation/Maintenance Mode
|
Front/Rear Installation/Maintenance
|
||||
|
Brightness（nits）
|
≥600
|
≥650
|
≥700
|
≥750
|
≥850
|
|
Uniformity of luminance
|
≥97%
|
||||
|
Horizontal/Vertical Viewing Angle
|
≥160°/≥140°
|
||||
|
Contrast
|
5000:1
|
||||
|
Module supply voltage DC
|
5v
|
||||
|
Module maximum current DC
|
3.8A
|
3.5A
|
3.2A
|
3A
|
|
|
Working input voltage AC
|
110—220V
|
||||
|
The maximum power consumption（w/pcs）
|
19
|
17.5
|
16
|
15
|
|
|
Working input voltage AC
|
110—220V
|
||||
|
Peak power consumption
|
1000w/m²
|
800w/m²
|
|||
|
Average power consumption
|
340w/m²
|
270w/m²
|
|||
|
Using Life
|
100,000hours
|
||||
|
Working Temperature
|
-10-+50℃
|
||||
|
Storage temperature
|
-20-+60℃
|
||||
|
Operating & Storage Humidity
|
20—80%
|
||||
